Blue Sea Systems - Push Button Reset Circuit Breaker Screw Terminal
$7.99
Save $-7.99
Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels,...
In stock at Outfitters — Cape May
Free expert assistance · (609) 884-0330
30-day easy returns · Free in-store pickup at both Cape May locations
Description
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- �Trip Free� design cannot be held �ON� during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
| Specifications | |
|---|---|
| Amperage | 15A |
| Maximum Voltage | 32V DC |
| Mounting | Panel Mount 3/8-27 UNS |
| Circuit Breaker Type | Thermal trip, manual push-button reset only |
| Terminal Type | #8 Screw |
Interrupt Capacity�
|
3000A @ 14.7V 2500A @ 28V |
| Minimum Operating Temperature | -10� C |
| Maximum Operating Temperature | 60� C |
| Screw Terminal Torque | 6 in-lb (0.68 Nm) |
| Weight | 0.06lb (0.03 kg) |
Specifications
Specifications
| Brand | Blue Sea Systems |
|---|---|
| Category | Breaker |
| SKU | BSS-2132 |
| Available amps | 10A, 15A, 3A, 5A, 7.5A |
